Multi-Span Plastic Film Greenhouse With No Vents-EU Plastic Film Greenhouse
Detailed Introduction
Product introduction
1. Feature/Advantage
- Modern appearance with strong structure; Gothic roof，No roof vents
- Higher arch design, more growing space, better greenhouse environment control;
- Prefabricated design, easy to assemble and dismantle;
- High light transmittance;
- Good thermal insulation performance;
- Stable and durable;
2. Scope of Application
EU Multi-span plastic film greenhouse can be used for growing vegetables, flowers, fruits and seedling; suitable for soil culture or soilless (substrate and hydroponic) culture. In addition, it also supports the practice of aquaponics farming and can be used as ecological restaurants.
3.Product Detail
| Cover material | Roof &Four side:HDPE/HDPO film, 150 micro /200micro thickness plastic film, single layer film, double layer film, inflated double layer film |
| Vents: High quality HDPE as raw materials, UV block.Mesh:25,32,40,50,60 optional | |
| Span width | 8/9/9.6/12.8m |
| Length | Can be customized |
| Section Length | 3~5m |
| Gutter Height | 4-5 |
| Ridge Height | 5.5~8.7m |
| Body Framework | Hot dip galvanized steel structure |
4.Climate Control System
NO | Item | Description | Including |
1 | Side ventilation system | Motorized roll up ventilation | Optional |
Manual roll up ventilation | Optional | ||
2 | Shading system | Inner shading system | Optional |
Outside shading system |
| ||
3 | Cooling system | Cooling pad&Exhaust fan system | Optional |
4 | Ventilation system | Circulation fans | Optional |
5 | Fogging system | High pressure fogging system | Optional |
6 | Heating system | Heat by hot air blower or boiler | Optional |
Key Word：
PC greenhouse
venlo greenhouse
nursery
What problems do greenhouses solve?
The primary benefit of greenhouse cultivation is the protection of crops from hazards such as adverse weather, pests, and diseases. Providing an enclosed growing area prevents crops from suffering damage from extreme climate-related events such as sudden changes in temperature, which helps improve cultivation efficiency, crop quality and crop yield.
I have a special project; can you customize your greenhouses?
Yes, we can customize the length and width of greenhouses based on your farm shape, size or project needs while ensuring that we maintain the same pricing. We also can customize the design, type and structure of the greenhouse according to your specifications and project budget.
Why are your prices so expensive?
We focus a lot more on product quality and customer satisfaction above anything else, to do this, we use the best raw materials to ensure we offer the best structures in the market. For example, all the steel frame parts that we use to construct your greenhouse are hot dip galvanized with hot SENDZIMIR galvanization treatment zinc cover 275g±/M2. It guarantees the optimal performance of anti-corrosion, with 15-year service life.
While cheaper options on greenhouses might exist in the market, more often than not, we find clients coming back to use to repair these structures due to the substandard materials used to construct them. In our view, greenhouses are a serious investment that warrants the need to ensure that your structure can last longer to give you the return you expect.
We do offer our best prices with discounts to ensure we give a competitive price to our customers.
Ask For A Quick Quote
We will contact you with in one working day,please pay attention to the Email with the suffix "@guniver.com"
Would you like to know more about our products? Please fill in the form on the left. In addition, you can send us a detailed list of your requirements.
The information we can provide:
√ Greenhouses
√ Climate control system
√ Seedling system
√ Cultivation system
√ Irrigation system
√ Greenhouse accessories
√ Farm House
